Using an Effects Unit inline with your T1® and Model II

If you want to connect an effects unit between your T1 ToneMatch Audio Engine and Model II you will need a T1 ToneMatch® Audio Engine Power Supply because you will not be using the ToneMatch cable that would normally supply the power to the T1 ToneMatch Audio Engine.

T1 Effect Unit Model II-1.png

T1 Effect Unit Model II-2.png
