Bose L1 Pro8 Compared to L1 Compact

From Bose Portable PA Encyclopedia FAQ & Wiki
Jump to: navigation, search

Questions and comments or LinkedIn @STPro.Thank youST.
FeatureBose L1 Pro8Bose L1 Compact
  L1 Pro8 51x200.jpg height:280px
Horizontal dispersion 180 degrees 180 degrees
Vertical dispersion 40 degrees (+/- 20 degrees) 40 degrees (+/- 20 degrees)
Output 112 dB / 118 dB peak 106 dB / 112 dB peak
Audience Up to 100 people Up to 100 people
Speaker Array Eight 2.00" (51 mm) high-excursion drivers mounted in a curved Articulated Array® Six 2.00" (51 mm) high-excursion drivers mounted in a curved Articulated Array® loudspeaker
Woofer One 7"x 13" neodymium racetrack transducer in the power stand One 8" (203 mm) low-frequency driver mounted in a ported bass enclosure in the power stand
Low Frequency
  • 45 Hz - 3dB
  • 65 Hz - 3dB
  • 50 Hz - -10 dB
Crossover

200 Hz

400 Hz

Power to speakers Biamped
  • 80 Watts RMS mid-high array
  • 240 Watts RMS sub
  • 320 Watts total
Biamped
  • 65 Watts RMS mid-high array
  • 65 Watts RMS sub
  • 130 Watts total
Weight Total system weight 18 kg (39.8 lb)
  • Power Stand: 14 kg (30.9 lb)
  • Mid-High array and extension: 4 kg (8.9 lb)
Total system weight 13.4 kg (30.2 lb)
  • Power Stand: 11.2 kg (24.6 lb)
  • Extensions (each): 1.1 kg (2.3 lb)
ToneMatch® Presets Channels 1 and 2
Full suite of ToneMatch Presets available in the ToneMatch mixers, built-in. Set using the L1 Mix App.
Channel 1
  • Fixed: Microphone

Channel 2

  • Acoustic Guitar
  • Line Level (flat)
Dimensions H x W x D 200.5 × 31.8 × 44 cm 18 kg

(78.9 × 12.5 × 17.3 in 39.8 lb)

41.8 x 33.9 x 42.6 cm (11.2 kg)

(78.5 x 13.25 x 16.75 in (24.6 lbs)

Battery No No
Connections

Channels 1 and 2
Combo Jacks
XLR / 6 mm (1/4" Tip-Ring or Tip-Ring-Sleeve) balanced / unbalanced
Channel 3/Aux Input

  • 6 mm (1/4" Tip-Ring or Tip-Ring-Sleeve) balanced / unbalanced
  • 3 mm (1/8" Tip-Ring-Sleeve) accepts stereo or mono input
  • Bluetooth input

Channel 1:
XLR balanced

Channel 2:

  • 6 mm (1/4" Tip-Ring or Tip-Ring-Sleeve) balanced / unbalanced
  • 3 mm (1/8" Tip-Ring-Sleeve) accepts stereo or mono input
  • Two RCA unbalanced phone plug
Tone Controls Channels 1 and 2
  • Bass / Treble

Channel 3

  • None
Channel 1
  • Bass / Treble

Channel 2

  • None
Line Out XLR balanced ¼ inch (6mm) jack: Nominal +2.2 dBu, Max +20 dBu
Note: Using a TS unbalanced cable will result in a drop in the audio level of -6dBu.
Bluetooth input Yes: Channel 3
Supports Bluetooth 5.x
No
Reverb Channels 1 and 2 Yes
Channel 3 None
No
ToneMatch Port Yes full support for T4S/T8S
power only for T1
No
System EQ Yes
Live/Music/Speech/Off
No
Scenes Yes
Store/recall system settings via Bose L1 Mix App
No
Bose L1 Mix App Yes
Wireless control over volume, tone, reverb and system EQ
No
